Connections

Electrical電源

3 PE AC400V 50/60Hz ±10%

能源

Pneumatic氣源

6 – 8 bar; oil-free and dry air

Unwinding放卷

Working width工作寬幅

650 -1’030 mm

Outside diameter卷徑

600 mm

Core – inner diameter卷芯

152 mm(6”)

Slitting分切

Slitting technique分切方式

Razor in air

Slitting widths分切寬幅

20 –1’000 mm , stepless adjustable

Rewinding收卷

Outside diameter卷徑

150 mmmax.

Core – inner diameter卷芯

25,4 mm(1”)

Main drive主驅動

Machine speed機器速度

100-400 m/min max.
(may be limited by material or core conditions跟物料和卷芯質量有關)

Leader applicator

Leader length引導膜長

max.1’100 mm

引導膜臺

Leader roll diameter引導膜卷徑

76 /250 mm

Leader width引導膜寬幅

100 –400 mm

Adhesive roll diameter膠帶卷徑

76 /200 mm

Adhesive roll widths膠帶寬幅

12 – 50 mm

Machine weight機器重量

approx.2’500 kg
